Product details
- Adopt STMicro TDA7498E chip to get clear audio sound, No pop, no audible noise, dead silent when nothing is playing through it.
- 160W X 2(4 ohms, 20 Hz - 20 kHz, 0.04% THD), for outdoor/ bookshelf/ computer/ desktop /ceiling /floor standing speakers, can use iPod, Phone, MP3 players, TV, Echo Dot, CD players, or Streaming Media players as input.
- 2.0CH audio integrated amplifier, aluminum enclosed, small size, good looks, simple functionality, and excellent sound quality;
- Home small Hi-Fi amp, Exclusively designed for the customers who pursue HiFi sound;
- You can return the item if you have any problems, 24-month warranty, feel free to contact us at support@fosiaudio.com
-
1. Power supply range: 12v-25v;
-
2. THD: ≤ 0.05%;
-
3. Frequency Range: 20Hz - 20kHz (±1 dB);
-
4. SNR: ≥ 98dB;
-
5. Input sensitivity: ≤ 280mV;
-
6. Terminating impedance: 2Ohm - 8Ohm;
-
7. Output power: MAX 160watt *2
-
8. Input mode: RCA
-
9. Supplied Accessories: Amplifier, Power supply, AC power cord, Manual.
FAQs
Please read our FAQs page to find out more.
How to: Choose the right banana plug?
- Closed Screw Type. All Fosi amplifiers use standard-sized speaker terminals (4mm pins).
- Easy to wire up and solidly connect to amplifier and passive speaker.
- If they do not fit, use a little force to tighten the plugs.
- Fosi Audio Banana Plugs (Copper, Silver/Gold Plated): http://bit.ly/40Djq0U, https://bit.ly/3MkPL8t
- Please watch tutorial videos: https://youtu.be/6pYhoqDlvNw / https://youtu.be/RGvBgGAwS9k
How to Diagnose Power Supply Failure?
- The following situations may cause this issue
- Case 1: The LED on the power supply does not light up; Case 2: Amp/Preamp does not turn on; Case 3: When plugged into the Amp, both light on the amp & power supply start blinking; Case 4: Amp/Preamp make noise; Case 5: Sound shuts off by itself
- Possible solution
- Check if the power supply is illuminated when plugged into AC by itself.
Plug power supply into a different socket.
Test the adapter with a meter.
Try a different power supply (within a range of DC input).
Test the included power supply on other electrical equipment.
Please watch the tutorial video by clicking on the link provided. https://youtu.be/yCjygS03zTE
What are the differences in power outputs using the 32V and 48V power supplies?
- Using a more powerful power supply can help prevent distortion.
- Enables amplifier to drive larger, more powerful, or higher-impedance speakers.
What is a GaN?
- The GaN supply has a power output of 240W.
- Offers overload and over-temperature protection.
- The 48V 5A GaN power supply is also available on Amazon.
