Built on User Voices

The ZP3 Balanced Preamp was developed in response to user demand for a preamplifier with multiple audio inputs.

  • Input: RCA x2 and XLR
  • Output: RCA, XLR, SUB
  • SNR≥ 115dB; SINAD≥113dB; Crosstalk≤ -130dB
  • Input Voltage Range: AC 110-240V

ZP3 & P4 Comparison

Thinking about a new preamp? Let’s line up P4 and ZP3, and see what makes each one special.

Product details

Description
  • Home Audio Control Hub: Features 3-in-3-out options for connecting up to three audio sources. Includes a remote control for one-touch input switching and volume adjustment—making it easy to manage your home audio system with freedom

  • Versatile Connectivity: Equipped with RCA1/RCA2/XLR inputs and RCA/XLR/Sub-Out outputs, the ZP3 integrates multiple devices with ease. Supports balanced XLR in/out for cleaner sound, plus RCA/XLR signal conversion for maximum compatibility
  • Audiophile-Grade Components: Built with premium parts including ELNA capacitors,  NJR NJU72315 volume IC, and gold-plated RCA jacks. These components reduce noise and distortion, delivering exceptional clarity and high-fidelity performance

  • Adjustable High-Pass Filter: Three-level HPF settings filter low-frequency signals from the RCA/XLR outputs, sending only mids and highs to main speakers while routing bass through the SUB-OUT—enhancing clarity, detail, and overall sound balance

  • Flexible Sound Customization: Includes bass/treble control with bypass function, and L/R balance knobs for personalized adjustment. Volume memory remembers settings for each input source—giving you a smarter, more convenient audio experience tailored to your taste
Specifications

Channel: 2.0
Input: RCA x2, XLR
Output: RCA, XLR, SUB
Bass and Treble Control Range: Treble: ±6dB,Bass: ±12dB
Frequency Response
XLR/RCA:
20Hz-20kHz (±0.2dB)
80Hz-20kHz (±0.2dB)
120Hz-20kHz (±0.2dB)
SUB: 20Hz-200Hz (±0.2dB)
Input Voltage Range: AC 110-240V

Balanced Output (XLR)
SNR: ≥ 112 dB
Dynamic Range: ≥ 112 dB
THD+N: ≤ 0.0007%
Noise Floor: ≤ 6μV

Single-Ended Output (RCA)
SNR: ≥ 115 dB
Dynamic Range: ≥ 115 dB
THD+N: ≤ 0.0008%
Noise Floor: ≤ 4μV

What‘s in the box?
  • Fosi Audio ZP3 x 1
  • IR Remote Control x 1
  • AC 110-240V Power Cord x 1
  • 12V Trigger Cable x 1
  • User Manual x 1

Which Product is right for you?

Compare products to find the best one for your needs.

From $199.99

Fosi Audio ZP3 Preamplifier

Type
Preamp
Input
RCA x2, XLR
Output
RCA, XLR, Sub-Out
Bass & Treble Control
Yes
THD+N
≤ 0.0007%
SNR
≥ 115 dB
From $99.99

Fosi Audio P4 Mini Preamplifier

Type
Preamp
Input
RCA x3
Output
RCA, Pre-Out
Bass & Treble Control
Yes
THD+N
≤ 0.003%
SNR
≥110dB
From $79.99

Fosi Audio P3 Tube Preamplifier

Type
Preamp+Headphone Amp
Input
Bluetooth, RCA
Output
RCA, 3.5mm Headphone Jack, AUX
Bass & Treble Control
Yes
THD+N
≤0.02%
SNR
≥103dB

FAQs

Please read our FAQs page to find out more.

One channel is louder than the other?

Make sure the balance knob is centered on the ZP3 and the input signal is balanced between the two channels.

What is the function of the Bypass switch?

It toggles tone control on/off. Slide up to bypass bass/treble; slide down to enable them. It doesn’t affect volume.

Can I switch between RCA and XLR output?

No. RCA and XLR outputs work at the same time and cannot be switched independently.

What is the function of the HPF adjustment?

It filters low frequencies, letting highs pass. The ZP3 offers 3 cutoff settings for different output frequency ranges.

Why is there no bass or the bass sounds weak?

Check if the HPF switch on the bottom is set to 20Hz–20kHz to avoid filtering out low frequencies. Also check if the bass knob is set too low.
